Experiment · Architecture

Connect Analyzer

A sales dashboard in .NET 10 and Next.js built as a craftsmanship experiment: the data source lives behind a port, so going from a mock to real SAP S/4HANA or Shopify is just writing a new adapter. The rest of the system never notices.

Live demo View on GitHub

The problem

I need to render a dashboard with SAP data. Today there is no SAP: there is a .txt mimicking its export. Tomorrow an OData sandbox; the day after, a real store. How do I structure the code so that this dance does not force me to rewrite the backend every time the source changes?

The solution

One port for the source

The ISalesRepository interface is the only contract that knows where data comes from. Everything else depends on the contract, never on the implementation.
Three adapters, one interface

Mock (.txt in Latin-1), SAP S/4HANA over OData, and Shopify over the Admin REST API. One env var (SalesSource) picks which one is wired at the composition root.
Persistence behind a second port

Ingestion reads from the source and saves into SQLite (ISalesStore); analytics read only from the store. Moving to Postgres would be another adapter, without touching the domain.
Actually deployed

Backend and mock on Google Cloud Run, frontend on Vercel, with automatic deploys via GitHub Actions and Workload Identity Federation (no keys stored as secrets).

Tech stack

Backend

.NET 10
C#
Hexagonal
Result/Error
SQLite
xUnit

Frontend

Next.js
TypeScript
App Router
Recharts

Infra & Deploy

Docker
Cloud Run
Vercel
GitHub Actions
OData (SAP)
Shopify

Technical decisions

Data source behind a port

An inviolable rule: ISalesRepository is the only thing that knows the source. Adding a new one = an outbound adapter + swapping its registration in Program.cs. The domain never finds out.
Result/Error instead of exceptions

Expected errors are values (Result), not exceptions. The adapter catches them at its edge; the controller is the only place that translates Error → HTTP. I cover it in detail in the post.
CI/CD without keys

The Cloud Run deploy authenticates with Workload Identity Federation: GitHub Actions gets ephemeral Google Cloud credentials without storing any service-account key as a repo secret.
